Export carbon Molecular Sieves CMS220 One 20GP Container
Carbon molecular sieves take the appearance of cylindrical black solid. To separate air into nitrogen and oxygen.
In industry, CMS can concentrate nitrogen from air with PSA systems, up to 98%~99.999% N2 purity.
Our CMS products have the character of large nitrogen yield capacity and high nitrogen recovery.
It can meet the requirement of all types of PSA nitrogen systems.
The carbon molecular sieve is in petroleum chemical industry,metal, the electronic manufacture and food preservation industries.
| Model | Carbon Molecular Sieve CMS220 | |||
| Appearance | Black, extruded(pellet) | |||
| Nominal pore diameter | 4 angstroms | |||
| Diameter (mm) | 0.95mm, 1.1-1.3mm, 1.3-1.5mm, 1.5-1.8mm | |||
| Crushing strength (The test temperature≤20℃) | >50 N/PC | |||
| Bulk Density | 630-680 KG/M3 | |||
| Dust level | 100PPM Max | |||
| Adsorbent time (S) (The test temperature≤20℃) | 2*50(can be adjusted) | |||
| Type | Adsorption Pressure (MPa) | N2 Purity(%) | N2 quantity (M3/T.MT) | Air/N2 (%) |
| CMS-220 | 0.75-0.8 | 99.999 | 55 | 6.8 |
| 99.99 | 100 | 4.8 | ||
| 99.9 | 145 | 3.7 | ||
| 99.5 | 220 | 2.6 | ||
Typical Application:
a) To separate air into N2 and O2. b) it is in petroleum chemical industry, the heat treatment of metal, the electronic manufacture and food preservation industries.
Zhongci three technicians go to Huhai factory to guide replacement of CMS according to the customers’ requirements. Moreover, the nitrogen production of the generator is 100 m3 / h, and the nitrogen purity requires to be more than 99.9%.
If any interest in our carbon molecular sieve in PSA nitrogen system, please feel free to contact us sales team. We can offer you professional and best cms solutions.
