Carbon molecular sieve for PSA nitrogen generator
Zhongci Carbon Molecular Sieve takes the appearance of cylindrical black solid, contains countless 4 angstrom fine pores.
It can be used to separate air into nitrogen and oxygen. In industry, CMS can concentrate nitrogen from air with PSA systems, up to 98%~99.999% N2 purity.
Our CMS products have the character of large nitrogen yield capacity; high nitrogen recovery. It can meet the requirement of all types of PSA nitrogen systems. The carbon molecular sieve is widely applied in petroleum chemical industry, the heat treatment of metal, the electronic manufacture and food preservation industries.
In the Process of generating Nitrogen, Carbon Molecular Sieve (CMS) plays a very vital role. With the help of CMS, only N2 is produced.
CMS takes up the carbon dioxide, oxygen, and other impurities and release the pure N2. PSA is one of the unique processes in which gases are separated with the help of pressure swing technology is called PSA.
|
Model
|
Carbon Molecular Sieve
|
|||
|
Appearance
|
Black, extruded(pellet)
|
|||
|
Nominal pore diameter
|
4 angstroms
|
|||
|
Diameter (mm)
|
0.95mm, 1.1-1.3mm, 1.3-1.5mm, 1.5-1.8mm
|
|||
|
Crushing strength (The test temperature≤20℃)
|
>50 N/PC
|
|||
|
Bulk Density
|
630-680 KG/M3
|
|||
|
Dust level
|
100PPM Max
|
|||
|
Adsorbent time (S) (The test temperature≤20℃)
|
2*50(can be adjusted)
|
|||
|
Type
|
Adsorption Pressure (MPa)
|
N2 Purity(%)
|
N2 quantity (M3/T.MT)
|
Air/N2 (%)
|
|
CMS-220
|
0.75-0.8
|
99.999
|
55
|
6.8
|
|
99.99
|
100
|
4.8
|
||
|
99.9
|
145
|
3.7
|
||
|
99.5
|
220
|
2.6
|
||
|
CMS-240
|
0.75-0.8
|
99.999
|
65
|
6.6
|
|
99.99
|
110
|
4.6
|
||
|
99.9
|
160
|
3.5
|
||
|
99.5
|
240
|
2.5
|
||
|
CMS-260
|
0.75-0.8
|
99.999
|
75
|
6.5
|
|
99.99
|
120
|
4.6
|
||
|
99.9
|
175
|
3.4
|
||
|
99.5
|
260
|
2.3
|
||
|
CMS-280
|
0.75-0.8
|
99.999
|
90
|
6.4
|
|
99.99
|
135
|
4.5
|
||
|
99.9
|
190
|
3.4
|
||
|
99.5
|
280
|
2.3
|
||
Pingxiang Zhongci Environmental Ceramics Material Co.,Ltd. was Founded in 2014, the company has been committed to the development, design and production of Zeolite Adsorbent, chemical catalytic support,Its main products include protective agents, proppants, molecular sieves, activated alumina, graphite Raschig rings, adsorbents and other products.
